GitHub – shivampkumar/trellis-mac · GitHub

Run TRELLIS.2 image-to-3D generation natively on Mac.

It is a port of Microsoft’s TRELLIS.2 – a state-of-the-art image-to-3D model – from CUDA-only to Apple silicon via PyTorch MPS. No NVIDIA GPU required.

produces 400K+ top mesh from single images in ~3.5 minutes on M4 Pro.

The output includes vertex-colored OBJ and GLB files ready for use in 3D applications.

• macOS on Apple Silicon (M1 or later)
• Python 3.11+
• 24GB+ integrated memory recommended (4B model is larger)
• ~15GB disk space for model load (first time download)

# Clone this repo
git clone https://github.com/shivampkumar/trellis-mac.git
cd trellis-mac

# Log into HuggingFace (needed for gated model weights)
hf auth login

# Request access to these gated models (usually instant approval):
#   https://huggingface.co/facebook/dinov3-vitl16-pretrain-lvd1689m
#   https://huggingface.co/briaai/RMBG-2.0

# Run setup (creates venv, installs deps, clones & patches TRELLIS.2)
bash setup.sh

# Activate the environment
source .venv/bin/activate

# Generate a 3D model from an image
python generate.py path/to/image.png

Output files are saved in (or use) the current directory. --output to specify the path).

# Basic usage
python generate.py photo.png

# With options
python generate.py photo.png --seed 123 --output my_model --pipeline-type 512

# All options
python generate.py --help

TRELLIS.2 depends on several CUDA-only libraries. This port replaces them with pure-Pytorch and pure-Python alternatives:

Additionally, all hardcoded .cuda() The calls throughout the codebase were patched to use active devices instead.

sparse 3d convolution (backends/conv_none.py): implements submanifold sparse convolution by creating a spatial hash of active voxels, aggregating neighboring features for each kernel position, applying weights via matrix multiplication, and scattering-adding the results back. Neighbor maps are cached per-tensor to avoid unnecessary computation.

take out the net (backends/mesh_extract.py): re-applies flexible_dual_grid_to_mesh Using Python dictionaries instead of CUDA hashmap operations. Creates a coordinate-to-index lookup table, finds associated voxels for each edge, and triangulates the quad using normal alignment projections.

Attention (patched full_attn.py): Adds an SDPA backend to the sparse attention module. Pads variable-length sequences in batches, runs torch.nn.functional.scaled_dot_product_attentionThen unpad the result.

Benchmarks on M4 Pro (24GB), pipeline type 512: :

Memory usage during generation is approximately 18GB of integrated memory.

• no texture export: Requires textured baking nvdiffrast (CUDA-only variational rasterizer). Meshes are exported with vertex colors only.
• Unable to fill holes: Mesh holes need to be filled cumesh (CUDA). There may be small holes in the mesh.
• slower than CUDA: Pure-PyTorch sparse convolution is ~10x slower than CUDA flex_gemm Fell. This is the main obstacle.
• no training support: Only guess.

The porting code (backend, patches, scripts) in this repository is released under the MIT License.

Upstream model weights are subject to their own licenses:

• TRELLIS.2 by Microsoft Research – original model and codebase
• DINOv3 by Meta – Image Feature Extraction
• RMBG-2.0 by BRIA AI – Background Removal
