giuseppe-coco/FireShow: 3D fireworks display design and visualization software

fireshow is a 3D fireworks display design and visualization software developed in C++ and OpenGL. Inspired by professional tools like FWSim and Finale 3D, this project allows designers to create, synchronize and visualize complex pyrotechnic effects in real-time 3D environments.

• Real-Time 3D Viewer: A scene rendered with OpenGL
• Advanced Particle System: Simulates the physics of various fireworks types, including cascading effects (trails) for advanced realism.
• Pre-defined fireworks types: Includes a library of ready-to-use classic effects like peonies, chrysanthemums, willows and volcanoes.
• Fireworks Editor: An integrated user interface (built with the beloved ImGui) that allows creating and modifying the properties of each firework type (color, velocity, particle count, etc.).
• Interactive Timeline: A control panel for placing fireworks events on the timeline with full playback controls (play, pause, reset).
• Integrated Audio: Each effect can be combined with launch and explosion sounds for a more immersive experience, powered by miniaudio Library.

• Language: C++17
• Graphics: OpenGL 3.3+
• Main Library:
  • GLFW: For window and input management.
  • Happy: To load OpenGL functions.
  • GLM: For mathematical operations related to graphics.
  • Dear Imguy: For graphical user interface.
  • stb_image: For texture loading.
  • MiniAudio: For audio playback.
• Manufacturing System: make (with g++,

This project uses make And g++The easiest way to get these tools on Windows is to use MinGW-w64 (Distributed via MSYS2).

1. Install MSYS2:

   • Download and install MSYS2 from the official website.
   • Follow the instructions to update the base system (running as usual). pacman -Syu After pacman -Su,

2. Install development toolchain:

   • Open an MSYS2 UCRT64 (or MINGW64) terminal.
   • install g++ compiler, makeAnd git With the following command:

     pacman -S --needed base-devel mingw-w64-ucrt-x86_64-toolchain git

3. Download GLFW:

   • This project requires pre-compiled GLFW libraries.
   • Go to GLFW download page and download “64-bit Windows binaries” For MinGW-w64.
   • Extract the zip file.

1. Clone the repository:

   git clone https://github.com/YOUR_USERNAME/YOUR_REPOSITORY.git
   cd YOUR_REPOSITORY

2. Configure Dependencies (GLFW):

   • Inside the root folder of the project, create the following directories: libs/glfw/include And libs/glfw/lib,
   • From the downloaded GLFW files, copy GLFW folder (which contains glfw3.h) In libs/glfw/include/,
   • from download lib-mingw-w64 Copy folder (or similar), files libglfw3.a And libglfw3dll.a In libs/glfw/lib/,

   The final folder structure for dependencies should look like this:

   /YOUR_REPOSITORY
   |-- /libs
   |   |-- /GLFW
   |       |-- /include
   |       |   |-- /GLFW
   |       |       |-- glfw3.h
   |       |-- /lib
   |           |-- libglfw3.a
   |   |-- /glad
   |       .......
   |..............
   |-- /src
   |-- /vendors
   |-- Makefile
   ...


1. Compile the project:

   • Make sure you are in the root directory of the repository within your MSYS2 terminal.
   • run make Permission:
   • This will compile all the source files and create the final executable FireworksSimulator.exe In bin/ Directory.

2. Run the software:

   • Execute the program with:

     ./bin/FireworksSimulator.exe

To remove all generated build files (objects and executables), run:
